XRF Spectrometer Gold Analyzer x ray gold tester detector

XRF Spectrometer Gold Analyzer:

Model No.: EDS5800C

Accuracy: 0.05% - 0.1%.

Detecting 17 elements.



Video

Specifications

Performance   and Configuration

Analysis   Range

1ppm to 99.99%

Accuracy

RSD ≤ 0.05% -- 0.1%

Sample   Form

Solid, powder, liquid

Tube   Voltage

5KV ~ 50KV

High   Voltage Power Supply

0 ~ 50KV Spellman (USA)

Camera

HD camera

Filters

Selectable customized   switches

Detector   Type

New Proportional Counter Tube

Multichannel   Analyzer

Multi channel simulation

Sample   Chamber Size

380 *380 * 60 (mm)

Test Time

10sec ~ 100sec

Measuring   Element

Au  Ag  Pt    Pd  Ni  Cu  Zn  Cd  In  Rh, etc. Total 17 elements

Analysis   Software

Qualitative and quantitative   analysis software

External   Dimensions

480 * 480 * 390 (mm)

Weight

38Kg

Instruments   Environmental Requirements

Ambient   Temperature

-5 ° C ~ 40 ° C (Suggested   that in air conditioning room)

Relative   Humidity

15% ~ 90%

Power   Requirements

AC 220V ± 5V, 50/ 60 Hz


No high   power electromagnetic and vibration interference sources nearby
