Model No.: EDS3900
Proportional Counter Tube Detector, Accuracy 0.1%
Video Link
https://youtu.be/RZZkdmsnjU4
Specifications
Performance and Configuration | |
Analysis Range | 1ppm to 99.99% |
Accuracy | RSD ≤ 0.1% |
Sample Form | Solid, powder, liquid |
Tube Voltage | 5KV ~ 50KV |
High Voltage Power Supply | 0 ~ 50KV Spellman (USA) |
Camera | HD camera |
Filters | Selectable customized switches |
Detector Type | Proportional Counter Tube |
Multichannel Analyzer | Multi channel simulation |
Sample Chamber Size | 380 *380 * 60 (mm) |
Test Time | 10sec ~ 100sec |
Measuring Element | Au Ag Pt Pd Cu |
Analysis Software | Qualitative and quantitative analysis software |
External Dimensions | 480 * 480 * 390 (mm) |
Weight | 39Kg |
Instruments Environmental Requirements | |
Ambient Temperature | -5 ° C ~ 40 ° C (Suggested that in air conditioning room) |
Relative Humidity | 15% ~ 90% |
Power Requirements | AC 220V ± 5V, 50/ 60 Hz |
No high power electromagnetic and vibration interference sources nearby | |
